15x20m 15x30m 20x30m Aluminum Frame Polygonal Event Tent
Curved Tent For Logistics / Warehouse /Express Logistics / Meetings / Party
♣ DESCRIPTION
Side Wall:PVC wall
Outer Cover Water proof Index:<3000mm
Feature: Water Proof / Fire Resistant/Wind Resisant / Snow Resistant
Application:Wearhouse/Hospital/Wedding Party / Outdoor Event / Trade Show Event/Sports event.
Wind Load:100km /h,can be reinforce
Snow Load:75kg/sqm.
| Frame | Hard pressed extruded aluminium 6061/T6(15HW) |
| Fabric cover | Double-Coated PVC Fabric,100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability. |
| Connector | Strong hot-dip galvanized steel |
| Space | No pole inside,100% available interior space. |
Sizes are customized.Each tent can be customized to suit any application or need, from color and
printing to side walls and accessories, from aluminum alloy frames that are durable ,each tent is
waterproof and flame retardant.
Features
1) Aluminium frame structure with PVC fabrics.
2)100% space usage, no pole inside.
3) Modular design structure, easy to install and dismantle.
4)Roof: 850g/sqm double PVC fabrics, black-out; Sidewalls: 650g/sqm double PVC fabrics, translucent;
both are fire retardant, UV resistance, water proof and mould proof, comply to DIN4102 B1; M2;
NFPA701; CAN/ULC S-109 etc.
5)One-stop inhouse manufacturing, from aluminium ingot smelting, profile extrusion, machining,
anodizing, PVC fabric cutting, high-frequency welding, fabrication of hardware parts & accessories.
On-site installation training available.
6)Strictly conducted in accordance with ISO 9001 & TS16949 management system, following documents available: fire retardant test report, wind loading report, structural analysis, installation manual, working instruction, inspection instruction etc.
-
Details reveal quality
-
-
-
OPTIONAL ACCESSORIES
1) covers: Colourful cover, white,transparent ,or other colours.
2) windows: Dome or square clear PVC windows, mesh window, glass window for glass wall
3) wooden flooring system: VIP, cassette, simple
4) doors: Double-swings glass door, single-swing glass door, glass fire door, hard PVC door
5) rolling door(automatic or manual)
6) sidewalls: Glass wall, PVC hard wall, sandwich panel wall, fiber glass wall
7) fixing methods: Ground anchors, weight plate, expandable screws
8) rain gutters (inner roof beam rain gutter or rain gutter between two tents)
9) lighting, AC, carpet, etc.
.
♣ MATERIAL DETAILS
Frame Material
Aluminum Alloy T6061/T6,hard pressed extruded aluminum alloy,anodized surface handing,silver color,sturdy and never rust,over 15-20 years life span.
Main profile:
84x48x3mm/ 122x68x3mm/ 166x88x3mm/ 203x112x4mm/ 120x254x4m/120x400x5m
/customized
Cover Material
Fabric cover:High quality double PVC-coated polyesster cextile,100% waterproof,flame retardant to
DIN4102 B1,M2,CFM,UV resistant,tear resistant, self-cleaning ability,etc.
The weight of fabric is from 650g/sqm to 850g/sqm.
Application of The Big Outdoor Tent
THis tent could be widely used for warehouse,storage,sports,party,wedding,and other bing events..
Outdoor exhibition
Warehouse
Logistics transshipment
Hangar
Military command center
Wedding
Season event,etc.
Such tent is easy to assemble and disassemble.We will supply installation manual and vedio.
If necessary,we can send a technician to guide the instalation .
